Product Details
Place of Origin: China
Brand Name: Taihong
Certification: ISO9001
Model Number: HJF80
Payment & Shipping Terms
Minimum Order Quantity: 1
Packaging Details: Export Standard
Delivery Time: 25 days
Payment Terms: TT, L/C, Western Union
Supply Ability: 500sets/month
Shot Weight: |
91.9/111/540grams |
Ejector Point: |
5 |
Machine Dimension: |
3.5m*1.2m*1.6m |
Tie Bar: |
315*315mm |
Shot Weight: |
91.9/111/540grams |
Ejector Point: |
5 |
Machine Dimension: |
3.5m*1.2m*1.6m |
Tie Bar: |
315*315mm |
80tons best price ISO9001T-slot high speed energy saving pvc plastics injection molding machine
home appliance injection molding machine is the type of fully-automatic machine, being provided with high efficiency, high reliability, high speed, low noise, low power consumption and other advantages
Machine main components adopt world famous brand, e.g.:
• PLC: TECHMATION CONTROLLER(Taiwan)
• AC Contactor: SIEMENS(Germany)
• Travel switch: SCHNEIDER(FRANCE),
• Transducer: NOVOTK (Germany)
• Proportional Valve: HNC(TAIWAN)
• Oil pump: VICKERS(USA)
• Directional Valve: VICKERS(USA)
• High-pressure pipe line: GOOD YEAR (USA)
Characteristics
1. Adopts the imported control components, durable, safe, and low failure rate.
2. Use human-computer interface, simple and more visually oriented.
3. The machine uses machine electrical and air linkage, excellent effect of bottom sealing.
4. East to adjust different sizes of cartons, adjust quickly and easily, available for a wide range of cartons.
5. Low power consumption, simple and convenient operation, low noise.
6. Use tap to seal the cartoon bottom, protected from weather, sealing reliable.
Shipping and Payment
| Product Name | 80 Injection molding machine price |
| Packing | Export standard package |
| MOQ | 1 set |
| FOB price | Please contact for new price |
| Delivery time | 25days |
| FOB port | Ningbo |
| Payment terms | T/T,L/C at sight |
Specification
| Injection Unit | UNIT | A | B |
| Screw diameter | mm | 32 | 36 |
| Screw L/D ratio | L/D | 21.5 | 19.8 |
| Shot size(theoretical) | CM³ | 101 | 123 |
| Injection weight(ps) | g | 91.9 | 111 |
| Injection rate | g/s | 70 | 82 |
| Injection pressure | Mpa | 188 | 148.5 |
| Screw speed | rpm | 0-220 | |
| Clamping Unit | |||
| Clamp tonnage | KN | 800 | |
| toggle Stroke | Mm | 275 | |
| Space Between tie Bars | mm | 315*315 | |
| Max.mold height | mm | 320 | |
| Min.mold height | mm | 120 | |
| Ejector Stroke | Mm | 80 | |
| Ejector tonnage | KN | 27 | |
| Others | |||
| Max.pump pressure | Mpa | 16 | |
| Pump motor power | KW | 9 | |
| Heater power | kw | 5.3 | |
| Machine size(L x W x H) | m | 3.5*1.2*1.6 | |
| Machine weight | Ton | 3 | |
| Oil tank capacity | L | 210 | |
