Ningbo Haijiang Machinery Co.,Ltd. sales@china-haijiang.com 86-574-88233242
Product Details
Place of Origin: China
Brand Name: Taihong
Certification: ISO9001
Model Number: HJF
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: negotiable
Packaging Details: Export standard
Delivery Time: 30days
Payment Terms: T/T
Supply Ability: 20sets/month
Injection Weight: |
91.9~111 |
Injection Rate: |
70~82 |
Clamp Tonnage: |
800 |
Toggle Stroke: |
275 |
Space Between Tie Bars: |
315*315 |
Machine Dimension: |
3.5*1.2*1.6 |
Injection Weight: |
91.9~111 |
Injection Rate: |
70~82 |
Clamp Tonnage: |
800 |
Toggle Stroke: |
275 |
Space Between Tie Bars: |
315*315 |
Machine Dimension: |
3.5*1.2*1.6 |
HJF-80 injection molding machine
Stable And Reliable Clamping Unit
Five-point double toggle diagonal structure, template design by computer optimization.
Mechanism, electronic & hydraulic triple interlock safety protection function.
Sensitive low-voltage mold protection device.
Multiple hydraulic liftout type
Multiple stages control for mold opening clamping pressure, speed positioning control
Hydraulic motor-driving gear mold adjustment.
Special technique treatment, reliable strength
Automatic centralized lubrication system
Mold open and clamping, liftout position control
Automatic mould adjustment function
Robotic pincher mechanical installation positioning interface.
Core pulling and inserting system is suitable for the complicate structure mould.
Specification
| Injection Unit | UNIT | A | B |
| Screw diameter | mm | 32 | 36 |
| Screw L/D ratio | L/D | 21.5 | 19.8 |
| Shot size(theoretical) | CM³ | 101 | 123 |
| Injection weight(ps) | g | 91.9 | 111 |
| Injection rate | g/s | 70 | 82 |
| Injection pressure | Mpa | 188 | 148.5 |
| Screw speed | rpm | 0-220 | |
| Clamping Unit | |||
| Clamp tonnage | KN | 800 | |
| toggle Stroke | Mm | 275 | |
| Space Between tie Bars | mm | 315*315 | |
| Max.mold height | mm | 320 | |
| Min.mold height | mm | 120 | |
| Ejector Stroke | Mm | 80 | |
| Ejector tonnage | KN | 27 | |
| Others | |||
| Max.pump pressure | Mpa | 16 | |
| Pump motor power | KW | 9 | |
| Heater power | kw | 5.3 | |
| Machine size(L x W x H) | m | 3.5*1.2*1.6 | |
| Machine weight | Ton | 3 | |
| Oil tank capacity | L | 210 | |
Haijiang Machinery Main Configuration
| Controller | Arcuchi/Porchesion(50-290T)(China) |
| Techmation(360-3000T)(Taiwan) | |
| Vane pump | Albert(USA) |
| Proportional valve | HJK series Northman(TAIWAN) |
| HJK series Northman(TAIWAN) or TOKIMEC(Japan) | |
| Directional valve | HNC(TAIWAN) or YUKEN(Japan) |
| Electric motor | Dongguan(Guangdong) |
| contactor | Mager(50-290T)/Schneider(China)(360-3000T) |
| High pressure hose | Fute(Ningbo) |
| Five-star hydrauhu | Dandun(China)STAFFA(UK) |
| Air breaker | LS(Korea) |
| Thermal overland relay | Schneider(China) |
| Limit switch | Omoron(Japan) |
| Lubrication pump | Automatic |
| Servo motor | SUMITOMO(Japan) |
| Servo pump | DELTA(Taiwan) |
| Servo sensor | ASHCROFT(Germany) |
SPARE PARTS(FOR FREE)
| 1.mold clamping with bolts:8pcs | 2.Nozzle:1pc |
| 3.Toolbox:1set | 4.heating ring:2pcs |
| 5.lubrication oil:1 bucket | 6.limit switch:2pcs |
| 7.hexagon wrench:1set | 8.thermocouple:2pcs |
| 9.seal ring:2pcs | 10.machine foot pad:6pcs |
| 11.vise:1pc | 12.power socket for auxiliary machine:2pcs |
| 13.wrench:1pc | 14.screwdriver:2pcs |
