Ningbo Haijiang Machinery Co.,Ltd. sales@china-haijiang.com 86-574-88233242
Product Details
Place of Origin: China
Brand Name: Taihong
Certification: iSO9001
Model Number: HJF200
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: negotiable
Packaging Details: Export standard
Delivery Time: 30days
Payment Terms: T/T
Supply Ability: 20sets/month
Injection Weight: |
314~470 |
Injection Rate: |
136~185 |
Clamp Tonnage: |
2000 |
Toggle Stroke: |
450 |
Space Between Tie Bars: |
500*470 |
Machine Dimension: |
5.3*1.4*1.9 |
Injection Weight: |
314~470 |
Injection Rate: |
136~185 |
Clamp Tonnage: |
2000 |
Toggle Stroke: |
450 |
Space Between Tie Bars: |
500*470 |
Machine Dimension: |
5.3*1.4*1.9 |
HJF-200 injection molding machine
injection Unit Advantages
Dual designed carriage cylinders ensure good balance and get high precise injection
No welding designed hydraulic circuit for injection unit, easy for maintain & no leaking.
Lightening designed moving parts for injection, easy to get the fast start injection speed, and meet high speed injection needs.
| SPECIFICATION | HJF-200 | |||
| A | B | C | ||
| Screw diameter | mm | 45 | 50 | 55 |
| Screw L/D Ratio | L/D | 20 | 18.8 | 18.8 |
| Shot size(theoretical) | cm³ | 349 | 431 | 522 |
| Injection weight(PS) | g | 314 | 388 | 470 |
| Injection pressure | Mpa | 220 | 180 | 150 |
| Injection rate | g/s | 136 | 170 | 185 |
| Screw Speed | rpm | 0~185 | ||
| Clamp tonnage | KN | 2000 | ||
| Opening stroke | mm | 450 | ||
| Space between the tie bars | mm | 500*470 | ||
| Max.Mold Height | mm | 500 | ||
| Min.Mold Height | mm | 180 | ||
| Ejector stroke | mm | 130 | ||
| Ejector tonnage | KN | 45 | ||
| Max.pump pressure | Mpa | 16 | ||
| Pump motor power | KW | 18.5 | ||
| Heater power | KW | 7.5 | ||
| Machine dimension(L*W*H) | M | 5.3*1.4*1.9 | ||
| Machine weight | T | 5.8 | ||
| Oil tank capacity | L | 240 | ||
Haijiang Machinery Main Configuration
| Controller | Arcuchi/Porchesion(50-290T)(China) |
| Techmation(360-3000T)(Taiwan) | |
| Vane pump | Albert(USA) |
| Proportional valve | HJK series Northman(TAIWAN) |
| HJK series Northman(TAIWAN) or TOKIMEC(Japan) | |
| Directional valve | HNC(TAIWAN) or YUKEN(Japan) |
| Electric motor | Dongguan(Guangdong) |
| contactor | Mager(50-290T)/Schneider(China)(360-3000T) |
| High pressure hose | Fute(Ningbo) |
| Five-star hydrauhu | Dandun(China)STAFFA(UK) |
| Air breaker | LS(Korea) |
| Thermal overland relay | Schneider(China) |
| Limit switch | Omoron(Japan) |
| Lubrication pump | Automatic |
| Servo motor | SUMITOMO(Japan) |
| Servo pump | DELTA(Taiwan) |
| Servo sensor | ASHCROFT(Germany) |
SPARE PARTS(FOR FREE)
| 1.mold clamping with bolts:8pcs | 2.Nozzle:1pc |
| 3.Toolbox:1set | 4.heating ring:2pcs |
| 5.lubrication oil:1 bucket | 6.limit switch:2pcs |
| 7.hexagon wrench:1set | 8.thermocouple:2pcs |
| 9.seal ring:2pcs | 10.machine foot pad:6pcs |
| 11.vise:1pc | 12.power socket for auxiliary machine:2pcs |
| 13.wrench:1pc | 14.screwdriver:2pcs |
