Product Details
Place of Origin: China
Brand Name: taihong
Certification: ISO9001
Model Number: Mould16
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: /
Packaging Details: Export Standard
Delivery Time: 30-60days
Payment Terms: TT, L/C, Western Union
Supply Ability: 500sets/month
Name: |
Spoon Fork Mold |
Life: |
300,000-300,0000shots |
Cavity: |
Single/multi |
Plastic Material: |
PP,PS,PC,PE,ABS,PVCetc. |
Specification: |
Depends On Customer’s Requirements |
Design Software: |
UG,PROE,CADetc. |
Mold Material: |
Steel |
Name: |
Spoon Fork Mold |
Life: |
300,000-300,0000shots |
Cavity: |
Single/multi |
Plastic Material: |
PP,PS,PC,PE,ABS,PVCetc. |
Specification: |
Depends On Customer’s Requirements |
Design Software: |
UG,PROE,CADetc. |
Mold Material: |
Steel |
2 set plastic mould , Steel Injection Molding Molds Single Cavities , machine for basin household
Plastic Injection Mould making
| Catalog | mould manufacturer |
| Brand | Moldie |
| Model | MLD-19M-009 |
| Mold Base | LKM, HASCO, DME or your requirement |
| Mold Material | 45#, P20, H13, 718, 1.2344, 1.2738 and so on |
| Standard | HASCO, DME, MISUMI, PUNCH and so on |
| Product Material | PC/ABS, ABS, PC, PVC, PA66, POM or other you want |
| Runner | Cold/Hot Runner |
| Gate Type | Side gate, Sub gate, Pin point gate, Edge gate etc |
| Mould Weight | 50kg-15Ton |
| Injection Machine Type | 80-1500Ton |
| Standard for Product Appearance for graining | MT(Mold Tech), YS, HN Series |
| The Way of Color Contrast for Plastic | RAL PANTONE |
| Certificated | ISO 9001:2008 Certificated, GSG Certificated |
Packaging & Shipping
|
1.we will send the mould productive process to the customer as their wish, picture or the video.
2.during the mould test we will send the sample to the customer.
3.before sending the mould , we will show the packing video (wooden case,painted with anti-rust) to the customer
4.if we keep the mould in our factory to produce the products ,life warranty. |
Some other terms for plastic injection mould:
| our commitment |
All customer-centric,never betray long-term benifits for short-term benfits. |
| our scope of mould business |
Mold,GARAGE KIT,injection molding,product assembly, surface printing,surface spraying integration |
| provide information as follow |
2D,3D,samples or pictures of multiple points of view with dimensions. |
| mould production cycles | 15--60days, on basis of the difficulty level |
| plastic products production cycles | 7--15days |
| mould precision | 0.1mm |
| service life |
500-1000 thousand times
|
| cavity number of mold |
Single cavity,Multiple cavity or one mold with different products |
| mould material | P20,2738,2344,718,S136,8407,NAK80,SKD61,H13 |
| runner system | Hot runner , Cold runner |
| surface treatment | Words corrosion,Mirror polish,Frosted surface,Dermatoglyph |
| mould standard | HASCO,DME or according to custom's request |
| main process |
Milling,grinding,CNC,EDM,wire-electrode cutting, carved, electrospark,lathe,surface treatment |
| design software | CAD, PRO-E, UG etc. |
| design time | Within 3 days(generally) |
| formed material |
ABS,PP,PC ,PA6,PA66, TPU,POM ,PBT,PVC,HIPS,PMMA, TPE,PC/ABS,TPV,TPO,TPR,EVA,HDPE. |
| quality assurance | ISO9001 |
| factory profile | 6000 square meters,100 employees including 8 inspectors |
