Product Details
Place of Origin: China
Brand Name: HAIJIA
Certification: CE,ISO9001
Model Number: Haijiang Micro
Payment & Shipping Terms
Minimum Order Quantity: 1 set
Price: USD6100
Packaging Details: wooden box standard export packing
Delivery Time: 20 days
Payment Terms: L/C, T/T, Western Union, D/P
Supply Ability: 30 sets per month
Machine Type: |
Small Machine |
Method: |
All Electric |
Shot Weight: |
Maximum 20 Grams |
Voltage: |
Custom |
Screw Size: |
16 Mm |
Nozzle Size: |
2 Mm |
Machine Type: |
Small Machine |
Method: |
All Electric |
Shot Weight: |
Maximum 20 Grams |
Voltage: |
Custom |
Screw Size: |
16 Mm |
Nozzle Size: |
2 Mm |
In order to participate in competition in the world market,the company has clustered a group of high quality technical and managerial personnel with innovative spirit by means of optimized combination fo personnel. The company faces the society and users by acting on the principle of pursuit for ?rst class and sincere service. We will appreciate friends from all circles who have given their concern and support to Haijiang machines with first class products and first class after service.
HAIJIANG MACHINERY MANUFACTURING CO.,LTD., situated in Ningbo Yinzhou Investment & Innovation Center, coversa land of more than 50,000M2.It was established in 1992 and now employs a staff of more than 500 people. with CE and ISO9001
High efficiency: 3.5s shaping cycle
Traditional hydraulic press:
Shot speed: 160~200mm/s
Molding cycle :7~10 /s
HaijiangMini:
Max shot speed: 500mm/s
Molding cycle 3.5 /s
SPECIFICATION | HJKMINI-8T |
VOLTAGE SUPPLY | 220V |
POWER COMSUMPTION | 1 KW |
NOZZLE SIZE | 3mm |
SCREW DIAMETER | 16 |
COOLING METHOD | Water cooling(or 220V mold temperature controller) |
MOLD INSTALLATION SIZE | 200*150*150(L*W*H) |
PLASTIC RAW MATERIAL | PP,PE,PA6,PS,PEI,PMMA,PVC,ABS etc |
PRODUCT WEIGHT | 20g |
MACHINE DIMENSIONS | 900*210*350(L*W*H) |
MACHINE WEIGHT | 100KG |
CLAMPING FORCE | 10T |
MOLD OPENING DISTANCE | 200mm |
EJECTION DISTANCE | 1-30mm |
TEMPERATURE RANGE | 0-500℃ |
MONITOR | TOUCH SCREEN |
CONTROL SYSTEM | PLC |
TRANSMISSION | CHAIN (or Timing belt pulley) |
SPACE BETWEEN TIE-BARS | 130mm*130mm |
SHELL | OPTIONAL |
AUXILIARY MACHINES(optional) | Auto loader,hopper dryer,mold temperature controller |
