Product Details
Place of Origin: China
Brand Name: Haijiang
Certification: ISO9001 CE
Model Number: HJF200
Payment & Shipping Terms
Minimum Order Quantity: 1
Packaging Details: Export Standard packing
Delivery Time: 25 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union
Supply Ability: 60 sets per month
Type: |
Medical Injection Molding Machine |
Size: |
200 T |
Type: |
Medical Injection Molding Machine |
Size: |
200 T |
Our plastic injection molding machine can make suction head,heat-free suction head,sample collection cup,vacuum blood collection tube.
haijiang focus on manufacturing medical consumables. can produce high-quality medical plastic products,specificalizing in the production of medical devices and reagents,products design and mold making,and provide production services.
| SPECIFICATION | HJF200 | |||
| Screw Type | A | B | C | |
| Screw Diameter | Mm | 45 | 50 | 55 |
| Screw L/D Ration | L/D | 20 | 18.8 | 18.8 |
| Shot Size(Theoretical) | cm3 | 349 | 431 | 522 |
| Injection Weight(PS) | g | 314 | 388 | 470 |
| Injection Rate | g/s | 136 | 170 | 185 |
| Injection Pressure | MPa | 220 | 180 | 150 |
| Screw Speed | rpm | 0~185 | ||
| Clamping Force | KN | 2000 | ||
| Opening stroke | Mm | 450 | ||
| Space Between Tie Bars | mm | 500*470 | ||
| Max.Mold Height | mm | 500 | ||
| Min.Mold Height | mm | 180 | ||
| Ejector Stroke | mm | 130 | ||
| Ejector Tonnage | KN | 45 | ||
| Max.Pump Pressure | MPa | 16 | ||
| Pump Motor Power | KW | 18.5 | ||
| Heater power | KW | 7.5 | ||
| Machine Dimension(L*W*H) | M | 5.3*1.4*1.9 | ||
| Machine weight | T | 5.8 | ||
| Oil Tank Capacity | L | 240 | ||
Adjustment Unit
Automatic Mold Height Adjustment Saves the time and cost during the mold changing.
Clamping Unit
The plates were designed using FEM software, ensuring a stable and rigid clamping system. Five point inward moving double toggle system ensures high rigidity and precision for mould clamping and also reducing stress and Strain effects.
Hydraulic Unit
The hydraulic system using the world famous pump and control valve can control the machine running precisely, ensuring the precision, reliability and durability of whole machine.
Injection Unit
Dual-pillar supporting and dual-cylinder injection balance devices ensure the stress on screw balanced during injection.
Specific screw and barrel designs are available for processing different material requirements.
Electronically Controlled Unit
1.CPU controller and display are independent and reliable.
2.A larger color LCD screen enhances clear display and supports multi-language compatibility.
3.The control system also supports remote monitor. In the event of a control problems, the machine can be connected to internet through a special interface. Inject service can realize remote fault diagnosis and maintenance.
4.A screen saver function extends the LCD life.
5.Ultra bright LED is provided for input and output point inspection. Proving convenient indication of the machine’s operation and machine service
6.A data hardware lock is provided to prevent unauthorized people from effecting the machines performance.
7.Closed Loop PID barrel temperature control.
8.Dust and waterproof control cabinets provide a neat and tidy enclosure all electrical control components.
